ICON A5 - Fuel Bladder (MY17 Only); Maintenance Instructions; Remove Fuel Bladder (MY17 Only)

FUEL SYSTEM / FUEL BLADDER (MY17 ONLY) 10-11
CHANGE C2 ICON A5 / MAINTENANCE MANUAL
CHAPTER 10
10.4 Fuel Bladder (MY17 Only)
10.4.1 Maintenance Instructions
10.4.1.1 Remove Fuel Bladder (MY17 Only)
The following procedure should be used to remove the fuel bladder.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
None
Parts Required
None
Aircraft System and Numb
07—Fuel System
Consumables
None
TASK INSTRUCTIONS:
1. Pump all fuel from bladder. (See “Pump Usable Fuel From Fuel Tank” on page 10-8.)
2. Remove the seat backs. (See “Seat Back Removal” on page 3-50.)
3. Remove the baggage sidewall panels. (See “Baggage Sidewall Panel Removal” on page 3-43.)
4. Use a 5/16 wrench to remove the nuts attached to forward end of the two hold down straps and
move the straps out of the way.
5. Disconnect the following electrical connections.
a. Disconnect D9038P from the optical switch.
b. Disconnect D9039P from the fuel level sensor.
c. With a 7/16 wrench, disconnect the T9028 ring terminal from the fuel level sensor access
plate.
d. With a 3/8 wrench, disconnect the ground strap at the fuel vent line from the tank’s fuel
filler flange.
