FUEL SYSTEM / FUEL TANK (MY18+) 10-15
CHANGE C2 ICON A5 / MAINTENANCE MANUAL
CHAPTER 10
10.5 Fuel Tank (MY18+)
10.5.1 Maintenance Instructions
10.5.1.1 Remove Fuel Tank (MY18+)
Use the following procedure to remove the fuel tank.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
None
Parts Required
None
Aircraft System and Number
07—Fuel System
Consumables
None
TASK INSTRUCTIONS:
1. Remove headliner. (See “Headliner Removal” on page 3-37.)
2. Remove baggage floor. (See “Baggage Floor Removal” on page 3-41.)
3. Remove baggage sidewall panels. (See “Baggage Sidewall Panel Removal” on page 3-43.)
4. Remove seat backs. (See “Seat Back Removal” on page 3-50.)
5. Pump all fuel from tank. (See “Pump Usable Fuel From Fuel Tank” on page 10-8.)
6. Disconnect the optical switch connector from D9038P. (See Figure 10-2.)
