ICON A5 - Seat Back Installation; Seat Back Removal

3-50 INSPECTIONS / GENERAL INSPECTION TASKS
ICON A5 / MAINTENANCE MANUAL CHANGE C2
CHAPTER 3
3. Install the three 8-32 attach screws with Tef-Gel
®
and torque each to 13 in-lb
f
with a T15 Torx
driver.
4. Install the armrest.
VERIFICATION METHOD:
The task is complete when the cockpit sidewall panel has been installed.
RELATED INFORMATION:
"Seat Back Installation" on page 3-51
3.6.2.13 Seat Back Removal
Use the following procedure to remove the seat back.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
None
Parts Required
None
Aircraft System and Number
NA
Consumables
None
TASK INSTRUCTIONS:
1. Remove cockpit sidewall panel adjacent to the seat back to be removed. (See “Cockpit Sidewall
Panel Removal” on page 3-48.)
2. Remove baggage floor adjacent to the seat back to be removed. (See “Baggage Floor Removal”
on page 3-41.)
3. Use a T20 Torx driver and 3/8 wrench to remove the seat back closeout behind the seat to be
removed.
