11.3 Seawings™
11.3.1 Maintenance Instructions
11.3.1.1 Seawings™ Platform Tip Removal and Installation
Remove and replace a Seawings™ platform tip. The tips are designed to be readily replaced in case of
damage.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
Owner/Pilot
Task Specific Training Required
No
Special Tools Required
None
Parts Required
ICA008108 (RH Seawings™ Tip)
ICA008109 (LH Seawings™ Tip)
Aircraft System and Number
08—Fuselage and Vertical Tail
Consumables
None
TASK INSTRUCTIONS:
1. Use a 3/8 wrench to remove the single AN3-C5A attachment bolt and two NAS1149C0363R
washers from inside the wheel well.
2. Firmly grasp the tip and pulling outward and aft, pull it off the Seawings™. There are four pins and
sockets—two forward and two aft—that will slide apart as the Seawings™ tip is removed.
3. Inspect the four pins on the Seawings™, verifying that all are securely bonded.
4. Before installing the original or replacement tip, inspect its condition, verifying no cracks or other
structural issues and that the four attachment bushings are in good condition and securely
bonded in place.
