ICON A5 - Fuselage and Vertical Tail General Maintenance; Canopy Removal

FUSELAGE AND VERTICAL TAIL / FUSELAGE AND VERTICAL TAIL GENERAL MAINTENANCE 11-3
CHANGE C1 ICON A5 / MAINTENANCE MANUAL
CHAPTER 11
11.2 Fuselage and Vertical Tail General Maintenance
11.2.1 Canopy Removal
Use the following procedure to remove the canopy.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
None
Parts Required
None
Aircraft System and Number
08—Fuselage and Vertical Tail
Consumables
None
TASK INSTRUCTIONS:
1. With the canopy raised and supported, use a wrench to remove the eight AN4C6A bolts and
91950A029 washers that secure the ICA005811 canopy hinge weldment to the canopy frame.
The bolts are threaded into blind nutplates. See Figure 11-1.
