ICON A5 - Condition and 100-Hour Inspection-Fuel Systems

INSPECTIONS / CONDITION INSPECTIONS AND 100-HOUR INSPECTIONS 3-13
CHANGE C2 ICON A5 / MAINTENANCE MANUAL
CHAPTER 3
3.3.3 Condition and 100-Hour Inspection—Fuel Systems
RELATED INFORMATION:
"Clear Fuel Tank Vent Line" on page 10-35
"Clear Filler Neck" on page 10-10
Correct all unsatisfactory items prior to flight
S=Satisfactory, U=Unsatisfactory
S U Comments
Fuel lines check for chafing/signs of
age/security/condition
Fuel tank leak check (inspect near low fuel level sensor,
access plate)
Fuel tank secure (inspect rubber strap isolators and
support isolators)
Sump fuel tank for water or debris
Fuel cap and neck secure
Fuel pump leak check/security
Check fuel valve for smooth operation and security
Clean coarse fuel filter (Replace if damaged)
Replace fine fuel filter
Perform leak check
Fuel tank vent system clear (See “Clear Fuel Tank Vent
Line” on page 10-35.) (See “Clear Filler Neck” on page
10-10.)
