7-2 ENVIRONMENTAL CONTROL (UTILITY SYSTEMS) / ENVIRONMENTAL CONTROL SYSTEM DESCRIPTION
ICON A5 / MAINTENANCE MANUAL CHANGE C1
7.1 Environmental Control System Description
Those units and components which furnish a means of heating, cooling and/or ventilate the internal
volumes of the fuselage. Includes: cabin heating unit with liquid transfer lines to engine radiator, cabin
fresh air eyeball vents, ducts, scoops and water/air separator.
