9-20 FLIGHT CONTROLS / ROLL CONTROLS
ICON A5 / MAINTENANCE MANUAL CHANGE C3
RELATED INFORMATION:
"Condition and 100-Hour Inspection—Wings" on page 3-11
"Exterior/Interior Wing Control Surfaces" on page 17-5
"Rigging Roll Controls" on page 9-20
"Inspect Roll Cable Tension" on page 9-13
"Rigging Yaw Controls" on page 9-87
"Rigging Pitch Controls" on page 9-46
9.4.4 Maintenance Instructions
9.4.4.1 Rigging Roll Controls
Use the following procedure for general maintenance and for rigging the roll control system following
disassembly, maintenance, and reassembly of the roll cable circuit.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
A&P
Task Specific Training Required
No
Special Tools Required
Aircraft Cable Tensiometer
Digital Protractor
5 x DIA .1875 Rigging Pins
1 x DIA .250 Rigging Pins
Parts Required
As needed based upon inspections and condition of parts. Contact ICON Aircraft for assistance
as needed. A list of part numbers in the aileron cable system is below.
Part Number Part Name Quantity
ICA002294 SOCKET ASSY, ROLL, WING FOLD 2
ICA005909 CONTROL CABLE, ROLL, FUSELAGE, UPR 1
ICA008437 CONTROL CABLE, ROLL, FUSELAGE, RH 2
ICA008437 BRACKET PLATE, PULLEY, ROLL, COCKPIT, AFT 2
