FLIGHT CONTROLS / ROLL CONTROLS 9-19
CHANGE C3 ICON A5 / MAINTENANCE MANUAL
pressure on the aileron trailing edge to remove play, record level reading at maximum trailing
edge down (TED) travel.
6. Have a helper move the control stick to raise the aileron trailing edge up against the stop (stop
contact at outboard roll bellcrank should be heard). Record level reading at maximum TEU travel
(the weight of the level should be enough to remove play without hand pressure).
RESULT:
Reg. No. of Aircraft:
Date of Test:
Initials of Technician:
VERIFICATION METHOD:
Record results and check against requirement.
Nominal Position
_______________
In-line with the flap trailing edge within ±.02 inch
Left Aileron ____° TED (15±2°) _________ ____° TEU (25±2°)
Right Aileron ____° TED (15±2°) _________ ____° TEU (25±2°)
