11-2 FUSELAGE AND VERTICAL TAIL / FUSELAGE AND VERTICAL TAIL DESCRIPTION
ICON A5 / MAINTENANCE MANUAL CHANGE C1
11.1 Fuselage and Vertical Tail Description
Structural units and associated components and members which make up the fuselage, cockpit, hull
and keel, ballast provision, water rudder and water rudder guard, Seawings™, center wing section, IPS
riser attachment(s), engine cowl and vertical tail including the air rudder and its hinges and counterbal-
ance. Includes: skins, bulkheads, ribs, fuselage-to-wing fillets, door/canopy jambs, as well as integral
or mounted aircraft hand-holds, tie downs and mooring cleats, mid, forward, and aft wing pin recepta-
cles, and firewall structure with thermal protection material(s) as required.
