11-14 FUSELAGE AND VERTICAL TAIL / WATER RUDDER
ICON A5 / MAINTENANCE MANUAL CHANGE C1
CHAPTER 11
RELATED INFORMATION:
"Re-Rigging Rudder Pedals" on page 9-103
"Installation of Water Rudder Cable" on page 11-17
11.4.2 Maintenance Instructions
11.4.2.1 Replace Water Rudder
The following should be used to replace the water rudder.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
None
Parts Required
M81934/2-05C012 Bushing
ICA008933 Cable
MS51844-22 Swage Fitting
AN100C-3 Thimble
Aircraft System and Number
08—Fuselage and Vertical Tail
Consumables
LOCTITE
®
603
LOCTITE
®
243™
TASK INSTRUCTIONS:
1. Install bushing M81934/2-05C012 into water rudder using LOCTITE
®
603, allow full cure prior to
continuing assembly.
2. Route new cable (ICA008933, FN 017) around the water rudder pulley, through the guide tubes
in the water rudder torque tube assembly, over the water rudder retraction pulleys, and through
the tail boom up to the existing turnbuckles and eye bolts.
3. Assemble water rudder into flange on aircraft using 91950A029 on the outside, and bolting
through the bushing ICA008934 and bolt with 97851A104 using LOCTITE
®
243™ and torque to
1/4 turn past sharp rise in torque.
