ICON A5 - Page 395

FUSELAGE AND VERTICAL TAIL / WATER RUDDER 11-17
CHANGE C1 ICON A5 / MAINTENANCE MANUAL
CHAPTER 11
RELATED INFORMATION:
"Removal and Installation of Inspection Panels and Fairings" on page 3-34
"Water Rudder Actuator and Cables" on page 11-11
11.4.2.3 Installation of Water Rudder Cable
The water rudder is actuated by cables. This task explains how to install the water rudder cables.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
Task Specific Training Required
No
Special Tools Required
Cable Swaging Tool
Parts Required
ICA008933 Cable
97855A510 Retaining Pin
MS24694C53 Screws
97851A104 Binding Post
91950A029 Washer
AN100C-3 Cable Thimble
Aircraft System and Number
08—Fuselage and Vertical Tail
Consumables
Tef-Gel
®
LOCTITE
®
609™
LOCTITE
®
243™
TASK INSTRUCTIONS:
1. Route a new cable (ICA008933, FN 017) around the groove in the ICA008933 Water Rudder
Puck, engaging the swaged ball on the cable in the mating recess in the puck.
2. Install a new retaining pin 97855A510 into puck.
3. Coat the sides of the puck, hardware, and cable that will be hidden, with a light coat of Tef-Gel
®
to help minimize water intrusion.
4. Slide the puck into the water rudder. The puck is properly oriented when the two mating screw
holes align and the swaged ball faces aircraft aft when rudder is in the retracted position.
