FUSELAGE AND VERTICAL TAIL / WATER RUDDER 11-11
CHANGE C1 ICON A5 / MAINTENANCE MANUAL
CHAPTER 11
11.4 Water Rudder
11.4.1 Inspection Instructions
11.4.1.1 Water Rudder Actuator and Cables
The water rudder is actuated by cables. This task is used to inspect those cables and the water rudder.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
T20 Torx driver
Flashlight
Inspection mirror
Parts Required
None
Aircraft System and Number
08—Fuselage and Vertical Tail
Consumables
None
TASK INSTRUCTIONS:
1. Use a T20 Torx driver to remove the aft bulkhead baggage panel attach screws. Remove the
panel. (See “Removal and Installation of Inspection Panels and Fairings” on page 3-34.)
2. Using a flashlight and inspection mirror as required, inspect attachment and integrity of the water
actuator, return spring, cables, turnbuckles, and attach points. These parts are located behind
the main landing gear bay, near the bottom of the hull. Pay particular attention to any corrosion
that may be forming on the steel cables. Any significant visible rust or broken cable fibers are
grounds for cable replacement. Now would be a good time to apply corrosion inhibiting oil to all
cables in the area.
3. Repeat step 2, while having a second person actuate the water rudder to the extended and
retracted position. While observing the actuator area, check for freedom of motion of all parts.
The return spring should maintain tension on the cable throughout the entire motion. There
should be no slack in the cable at any time.
