9-46 FLIGHT CONTROLS / PITCH CONTROLS
ICON A5 / MAINTENANCE MANUAL CHANGE C3
RELATED INFORMATION:
"Condition and 100-Hour Inspection—Aft Fuselage and Empennage" on page 3-19
9.6.4 Maintenance Instructions
9.6.4.1 Rigging Pitch Controls
Use the following procedure for elevator rigging.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
A&P
Task Specific Training Required
No
Special Tools Required
Aircraft Cable Tensiometer
Parts Required
As needed based upon inspections and condition of parts. Contact ICON Aircraft for assistance
as needed. A list of part numbers in the elevator cable system is below.
Number Name Quantity
ICA002203 SECTOR ASSY, PITCH, AFT 1
ICA002491 CONTROL CABLE, PITCH, FWD-UPR 1
ICA002495 CONTROL CABLE, PITCH, FWD-LWR 1
ICA002504 CONTROL CABLE, PITCH, AFT-UPR 1
ICA002508 CONTROL CABLE, PITCH, AFT-LWR 1
ICA008756 BRACKET ASSY, PITCH SECTOR 1
NAS77C4-005 BUSHING, FLNGD, UNLINED, CRES, .250X.050 2
ICA009226 BUSHING, FLANGED, .250X.085X.032 2
MS20392-1R41 PIN, STR, HEADED, DRILLED SHK, CRES, .125X1.281 1
