FLIGHT CONTROLS / ROLL TRIM TAB 9-37
CHANGE C3 ICON A5 / MAINTENANCE MANUAL
CHAPTER 9
cates that a longer tab is needed, contact ICON Aircraft for support
as this may be an indication of some other problem.
RELATED INFORMATION:
"Remove Roll Trim Tab" on page 9-37
9.5.4 Maintenance Instructions
9.5.4.1 Remove Roll Trim Tab
Use these instructions to remove the roll trim tab and clean the leftover adhesive residue from the
aileron control surface.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
None
Parts Required
None
Aircraft System and Number
Trim Tab Length (in) Time to Roll 10° (sec) Time to Roll 20° (sec)
0∞∞
22136
4814
6610
847
10 3 6
12 <3 5
