ICON A5 - Cockpit Sidewall Panel Installation

INSPECTIONS / GENERAL INSPECTION TASKS 3-49
CHANGE C2 ICON A5 / MAINTENANCE MANUAL
CHAPTER 3
TASK INSTRUCTIONS:
1. Remove the armrest pad. It is secured with hook and loop material.
2. Use a T15 Torx driver to remove the two 8-32 screws that were under the pad.
3. Use a T15 Torx driver to remove the one 8-32 screw in the side panel pocket.
4. Pulling in an inward and forward direction, pull panel out, taking care that the flange on the panel
does not scratch the forward part of the seat bottom.
VERIFICATION METHOD:
The task is complete when the steps have been completed and the cockpit sidewall panel has been
removed.
RELATED INFORMATION:
"Seat Back Removal" on page 3-50
3.6.2.12 Cockpit Sidewall Panel Installation
The following procedure should be used to install the cockpit sidewall panel.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
None
Parts Required
None
Aircraft System and Number
NA
Consumables
Tef-Gel
®
TASK INSTRUCTIONS:
1. Inspect the area behind the panel to ensure nothing is out of place.
2. Locate the panel in position being careful not to scratch anything.
