ICON A5 - Maintenance Instructions; Battery Removal and Installation

ELECTRICAL SYSTEM / BATTERY 6-37
CHANGE C2 ICON A5 / MAINTENANCE MANUAL
CHAPTER 6
6.5.3 Maintenance Instructions
6.5.3.1 Battery Removal and Installation
The Concord RG-25XC, 12V, 25AH main aircraft battery is removed and installed by using the proce-
dures given.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
None
Parts Required
CONCORD RG-25XC, 12V, 25 AH BATTERY
8997K53 POLYURETHANE STRIP
Aircraft System and Number
03—Electrical System
Consumables
None
TASK INSTRUCTIONS:
1. Remove the Right Top Instrument Panel Cover. (See “Right Instrument Panel Top Panel
Removal” on page 8-17.)
2. Disconnect the cabling from the negative battery terminals.
3. Disconnect the cabling from the positive battery terminals.
4. Remove the Battery Hold Down bracket nuts and bracket with a 7/16 wrench.
5. Remove the battery from the battery box.
Battery Installation
6. Install 8997K53 Polyurethane strip around the perimeter of the battery flush with the base. Cut
to length needed to allow seam gap of less than 1.5”.
7. Install the battery into the battery box with terminals toward the right side of the aircraft.
8. Install the Battery Hold Down bracket with nut and washer as removed. Hand tighten the nuts
ensuring the bracket sits evenly across the battery then torque each side to 44 in-lb
f
with a 7/16
wrench.
