ICON A5 - Baggage Sidewall Panel Installation

INSPECTIONS / GENERAL INSPECTION TASKS 3-43
CHANGE C2 ICON A5 / MAINTENANCE MANUAL
CHAPTER 3
None
Parts Required
None
Aircraft System and Number
NA
Consumables
None
TASK INSTRUCTIONS:
1. Install the left baggage floor with its two spacers at the outboard screw locations.
2. Install the right baggage floor with its four spacers at its four corners.
3. Install the six 10-32 screws and tighten with a T20 Torx driver to 26 in-lb
f
.
VERIFICATION METHOD:
The procedure is complete when the baggage floor is installed.
RELATED INFORMATION:
"Baggage Sidewall Panel Installation" on page 3-45
"Fuel Level Sensor Replacement" on page 6-72
"Seat Back Installation" on page 3-51
"Main Landing Gear (MLG) Removal" on page 14-37
"Main Landing Gear (MLG) Installation" on page 14-38
"Rigging Roll Controls" on page 9-20
"Inspect Roll Cable Tension" on page 9-13
"Rigging Yaw Controls" on page 9-87
"Rigging Pitch Controls" on page 9-46
"Seat Belt Replacement" on page 8-3
"Install Fuel Tank (MY18+)" on page 10-19
3.6.2.7 Baggage Sidewall Panel Removal
Use the following task to remove the baggage sidewall panel.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
