3.6.2.8 Baggage Sidewall Panel Installation
Use the following procedure to install the baggage sidewall panel.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
None
Parts Required
None
Aircraft System and Number
NA
Consumables
None
TASK INSTRUCTIONS:
1. Locate the sidewall panel into rough position, then lift its upper edge up so as to engage the two
carbon tabs.
2. Align the three holes with the underlining structure and install the three push-clip fasteners.
Pushing their center buttons in flush once in place, will expand their locking feature.
3. Install the seat belt reels. (See “Seat Belt Inertia Reel Installation” on page 3-40.)
