EQUIPMENT AND FURNISHINGS / EQUIPMENT AND FURNISHINGS GENERAL MAINTENANCE 8-5
CHANGE C1 ICON A5 / MAINTENANCE MANUAL
5. Install the seat belt buckle side of the belt assembly onto the inboard keel as shown in Figure 8-2.
Torque the bolt to 90 in-lb
f
.
6. Install the free end of the seat belt assembly into the outboard longeron as shown in Figure 8-1.
Torque the fastener to 85 in-lb
f
.
7. Install the seat belt inertia reel. (See “Seat Belt Inertia Reel Installation” on page 3-40.)
8. Verify proper function of the inertia reel.
9. Install the seat pan, seat back, seat back closeout, and baggage floors (See “Seat Pan Installa-
tion” on page 3-53.)(See “Seat Back Installation” on page 3-51.)(See “Baggage Floor Installation”
on page 3-42.).
VERIFICATION METHOD:
Procedure is complete when steps are finished.
RELATED INFORMATION:
"Baggage Floor Removal" on page 3-41
"Seat Back Removal" on page 3-50
"Seat Pan Removal" on page 3-52
"Baggage Floor Installation" on page 3-42
"Seat Back Installation" on page 3-51
"Seat Pan Installation" on page 3-53
8.2.2 Center Console Bucket Removal
Use the following procedure to remove the center console bucket.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
None
Parts Required
None
Aircraft System and Number
05—Equipment and Furnishing
Consumables
