8-6 EQUIPMENT AND FURNISHINGS / EQUIPMENT AND FURNISHINGS GENERAL MAINTENANCE
ICON A5 / MAINTENANCE MANUAL CHANGE C1
CHAPTER 8
None
TASK INSTRUCTIONS:
1. Remove 2X Screws which secure the FWD edge of the center console bucket. Retain all
fastening hardware. See Figure 8-3.
FIGURE 8-3
FWD EDGE BUCKET SCREWS
2. Remove 2X Screws which secure the center armrest. Retain all fastening hardware. See Figure
8-4.



