EQUIPMENT AND FURNISHINGS / EQUIPMENT AND FURNISHINGS GENERAL MAINTENANCE 8-19
CHANGE C1 ICON A5 / MAINTENANCE MANUAL
CHAPTER 8
#2 right-angle crosshead driver
Eyeball Vent Tool (ITL001563)
Aircraft System and Number
05—Equipment and Furnishing
Consumables
LOCTITE
®
243™
TASK INSTRUCTIONS:
1. Install right instrument panel top first by locating it in position, then:
a. Install air vent hose and clamp.
b. Install 6-32 screw with washer under it head behind right eyeball air valve, torquing to 9
in-lb
f
.
c. Install 8-32 screws at right-forward side of and aft-left corner of panel, torquing each to 13
in-lb
f
.
2. Install right eyeball air valve using eyeball vent tool (ITL001563), aligning tooling holes to 6 and
12 o’clock positions.
3. Install Throttle Handle and Bezel. (See “Throttle Handle and Bezel Installation” on page 8-13.)
4. Install the Center Console Bucket. (See “Center Console Bucket Installation” on page 8-8.)
5. Install the GPS in its mount.
VERIFICATION METHOD:
The procedure is complete when the right instrument panel top panel has been completely reinstalled.
RELATED INFORMATION:
"Battery Removal and Installation" on page 6-37
"Heater Fan and Core Installation" on page 7-4
"Multiple Systems Controller (MSC) Replacement" on page 13-27
"Canopy Removal" on page 11-3
"Canopy Installation" on page 11-4
"Nose Landing Gear (NLG) Leg Assembly Installation" on page 14-62
"Install Landing and Taxi Lights" on page 6-60
"Landing Gear Actuator Limit Switch Adjustment Procedure" on page 14-19
8.2.10 Left Instrument Panel Top Panel Removal
Use the following procedure to remove the left instrument panel top panel.
TASK INFORMATION:
Type of Maintenance
Line
