8-20 EQUIPMENT AND FURNISHINGS / EQUIPMENT AND FURNISHINGS GENERAL MAINTENANCE
ICON A5 / MAINTENANCE MANUAL CHANGE C1
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
T15 Torx driver
#2 right-angle crosshead driver
Eyeball Vent Tool (ITL001563)
Aircraft System and Number
05—Equipment and Furnishing
Consumables
None
1. Remove Center Console Bucket.(See “Center Console Bucket Removal” on page 8-5.)
2. Remove the throttle handle and bezel.(See “Throttle Handle and Bezel Removal” on page 8-10.)
3. Remove the two kneepads by carefully peeling them off. They are held on with hook and loop
tape.
4. Remove GPS mount and Radio stack bezel. (See “GPS Mount and Radio Stack Bezel Removal”
on page 8-15.)
5. Remove the ICA008624 cluster hood.(See “Replace Instrument Panel Gauge” on page 13-26.)
6. Remove the vent air hose at left side instrument panel top panel by loosening the worm drive
clamp.
7. Remove the left eyeball air valve using ICON tool ITL001563.
8. Remove the 6-32 screw behind the left eyeball air valve with a #2 right-angle crosshead driver.
9. Remove the 8-32 screws at the forward-left side and at aft-right corner of the left instrument
panel top panel with a T15 Torx driver. Remove the left instrument panel top panel being careful
not to damage the instrument cluster.
VERIFICATION METHOD:
The procedure is complete when the entire left instrument panel top panel has been completely
removed.
