ICON A5 - Inspection Instructions; Inspect Pitch Cable Tension

9-42 FLIGHT CONTROLS / PITCH CONTROLS
ICON A5 / MAINTENANCE MANUAL CHANGE C3
CHAPTER 9
9.6.3 Inspection Instructions
9.6.3.1 Inspect Pitch Cable Tension
This section contains instructions to check elevator cables for correction tensions.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
Tensiometer
Parts Required
None
Aircraft System and Number
06—Flight Controls
Consumables
None
TASK INSTRUCTIONS:
1. Remove left hand and right hand forward and main cockpit floor boards. (See “Cockpit Floor
Board Removal” on page 3-46.)
2. Remove seat back and seat pan. (See “Seat Back Removal” on page 3-50.) (See “Seat Pan
Removal” on page 3-52.) Retain all fastening hardware.
3. Remove AFT bulkhead baggage panel. (See “Baggage Sidewall Panel Removal” on page 3-43.)
Retain all fastening hardware.
4. Install .250 in diameter rig pin through the center console and forward pitch sector. See “Rig Pin
Location” on page 9-43.
