ICON A5 - Seat Belt Inertia Reel Removal

INSPECTIONS / GENERAL INSPECTION TASKS 3-39
CHANGE C2 ICON A5 / MAINTENANCE MANUAL
CHAPTER 3
Parts Required
None
Aircraft System and Number
NA
Consumables
None
TASK INSTRUCTIONS:
1. Position the headliner in rough position and connect the two headset hanger light connectors.
2. Align and push the headliner up and into place.
3. Install the overhead console bezel by engaging the tabs at the aft edge, then swinging the
forward edge up until the spring fasteners snap into place.
4. Push the four light control knobs onto their D-shafts.
VERIFICATION METHOD:
Task is complete when headliner is installed.
RELATED INFORMATION:
"Fine Fuel Filter" on page 10-30
"Rigging Roll Controls" on page 9-20
"Inspect Roll Cable Tension" on page 9-13
"Rigging Yaw Controls" on page 9-87
"Rigging Pitch Controls" on page 9-46
"Install Fuel Tank (MY18+)" on page 10-19
"Install Fuel Pressure Sensor" on page 6-69
"Install Fine Fuel Filter" on page 10-33
3.6.2.3 Seat Belt Inertia Reel Removal
Use this procedure to remove the seat belt inertia reel.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
