EQUIPMENT AND FURNISHINGS / EQUIPMENT AND FURNISHINGS GENERAL MAINTENANCE 8-17
CHANGE C1 ICON A5 / MAINTENANCE MANUAL
CHAPTER 8
TASK INSTRUCTIONS:
1. Install the GPS mount and radio stack bezel at the same time. Do this by first interlocking the two
parts together. Then, while holding the lower edge of the radio bezel away from the center
console, engage the tabs at the upper edge of the GPS mount and push the assembly into place.
2. Install the two 8-32 mounting screws in the GPS mount and the four 8-32 screws that mount the
radio bezel, torquing all to 13 in-lb
f
.
VERIFICATION METHOD:
The procedure is complete when the GPS mount and radio stack bezel has been installed.
RELATED INFORMATION:
"Center Console Bucket Installation" on page 8-8
"Throttle Handle and Bezel Installation" on page 8-13
"GPS Mount and Radio Stack Bezel Removal" on page 8-15
8.2.8 Right Instrument Panel Top Panel Removal
Use the following procedure to remove the right instrument panel top panel.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
T15 Torx driver
#2 right-angle crosshead driver
Eyeball Vent Tool (ITL001563)
Parts Required
None
Aircraft System and Number
05—Equipment and Furnishing
Consumables
None
