ICON A5 - Baggage Floor Installation; Baggage Sidewall Panel Removal

3-42 INSPECTIONS / GENERAL INSPECTION TASKS
ICON A5 / MAINTENANCE MANUAL CHANGE C2
CHAPTER 3
None
Aircraft System and Number
NA
Consumables
None
TASK INSTRUCTIONS:
1. Use a T20 Torx driver to remove the six 10-32 screws, one at each corner of the two floors.
2. Remove the right floor, then the left floor, being careful not to lose the six associated spacers if
they have come loose.
VERIFICATION METHOD:
Task is complete when both right and left floors are removed.
RELATED INFORMATION:
"Baggage Sidewall Panel Removal" on page 3-43
"Fuel Level Sensor Replacement" on page 6-72
"Seat Back Removal" on page 3-50
"Main Landing Gear (MLG) Removal" on page 14-37
"Main Landing Gear (MLG) Installation" on page 14-38
"Rigging Roll Controls" on page 9-20
"Inspect Roll Cable Tension" on page 9-13
"Rigging Yaw Controls" on page 9-87
"Rigging Pitch Controls" on page 9-46
"Seat Belt Replacement" on page 8-3
"Remove Roll Cables" on page 9-28
"Remove Fuel Tank (MY18+)" on page 10-15
3.6.2.6 Baggage Floor Installation
Use the following procedure to install the baggage floor.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
