14-38 LANDING GEAR / MAIN LANDING GEAR
ICON A5 / MAINTENANCE MANUAL CHANGE C2
5. Use a 7/16 wrench to hold the aft union fittings at the parking brake valve, then use a 1/2 wrench
to loosen the B-nuts, disconnecting the left and right brake lines from the aft side of the valve.
Cap the line and valve openings to minimize brake fluid loss.
6. Use a tool such as a putty knife to separate and peel the bond between the flanges of the left
and right MLG boot and the Seawings™ being careful to not damage the surfaces.
7. Remove all the cable ties that secure the left and right brake lines from the parking brake valve
back to the gear.
8. The brake lines pass through grommets at the forward main bulkhead. Push these aft into the
gear bay.
9. Supporting the weight of the left gear leg, remove the retaining ring and wrist pin securing the
left MLG pushrod to the MLG bellcrank.
10. Use 15/16 wrenches to remove the two AN10C20A pivot bolts, nuts, and washers from the left
11. Withdraw the left MLG leg assembly from the aircraft, guiding the brake lines through the bulk-
head.
12. Disconnect the MLG actuator from the aircraft electrical harness.
13. Use a 3/8 wrench to remove the AN3C27A bolt washer from the top of the MLG bellcrank.
14. Supporting the weight of the right gear leg, use 15/16 wrenches to remove the two AN10C20A
pivot bolts, nuts, and washers from the right MLG trunnion.
15. Remove the retaining ring from the MLG bellcrank shaft, then remove the shaft.
16. Withdraw the right MLG leg, bellcrank, and actuator assemblies from the aircraft, guiding the
brake line out through the bulkhead.
17. Proceed to the Beringer Wheel and Brake Maintenance Manual if changing the tire or doing
further work on the wheel.
VERIFICATION METHOD:
The procedure is complete when the main landing gear has been removed.
RELATED INFORMATION:
"Seat Back Removal" on page 3-50
"Seat Back Installation" on page 3-51
"Baggage Floor Removal" on page 3-41
"Baggage Floor Installation" on page 3-42
"Main Landing Gear (MLG) Boot Removal" on page 14-41
"Main Landing Gear (MLG) Boot Installation" on page 14-42
"Inspect Flap Rigging" on page 9-65
14.6.1.2 Main Landing Gear (MLG) Installation
The following procedure should be used to install the main landing gear (MLG).
TASK INFORMATION:
