INSPECTIONS / GENERAL INSPECTION TASKS 3-51
CHANGE C2 ICON A5 / MAINTENANCE MANUAL
CHAPTER 3
4. Use a 3/8 wrench to remove the lower 10-32 bolts from seat back, one 10-32 bolt in the side of
the center console and two 10-32 bolts from the outboard side of seat back.
5. Lift out seat back carefully so as not to scratch paint or damage the seat belt.
VERIFICATION METHOD:
The task is completed with the seat back has been removed.
RELATED INFORMATION:
"Fuel Level Sensor Replacement" on page 6-72
"Cockpit Sidewall Panel Removal" on page 3-48
"Baggage Floor Removal" on page 3-41
"Remove Fuel Bladder (MY17 Only)" on page 10-11
"Seat Pan Removal" on page 3-52
"Main Landing Gear (MLG) Removal" on page 14-37
"Main Landing Gear (MLG) Installation" on page 14-38
"Rigging Roll Controls" on page 9-20
"Inspect Roll Cable Tension" on page 9-13
"Rigging Yaw Controls" on page 9-87
"Rigging Pitch Controls" on page 9-46
"Seat Belt Replacement" on page 8-3
"Remove Roll Cables" on page 9-28
"Remove Fuel Tank (MY18+)" on page 10-15
3.6.2.14 Seat Back Installation
The following procedure is used to install the seat back.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
None
Parts Required
None
Aircraft System and Number
NA
