FLIGHT CONTROLS / PITCH TRIM TAB 9-63
CHANGE C3 ICON A5 / MAINTENANCE MANUAL
VERIFICATION METHOD:
Record results and check against requirements.
RELATED INFORMATION:
"Install Pitch Trim Actuator" on page 9-55
9.8.3.2 Measure Pitch Trim Tab Wear
Use the following procedure to measure wear of the pitch trim tab.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
None
Parts Required
None
Aircraft System and Number
06—Flight Controls
Consumables
None
1. Hold the elevator so that its trailing edge aligns with the horizontal tail tips (take the average if
left and right align differently) throughout this procedure. Use adhesive tape between elevator
trailing edge and elevator tips to temporarily align the elevator to neutral deflection in alignment
with the horizontal tail tips.
2. Secure digital inclinometer to the top of the trim tap surface with double-side tape. Ensure that
its long axis is perpendicular to tab hinge line and that it does not interfere with tab operation.
3. Operate the trim tab until its trailing edge aligns with that of the elevator. Zero the inclinometer.
Pitch Trim Tab ____° TED (21±2°) ____° TEU (15±2°)
