3-38 INSPECTIONS / GENERAL INSPECTION TASKS
ICON A5 / MAINTENANCE MANUAL CHANGE C2
1. Remove the four light control knobs from the overhead console by pulling each down and off
their D-shafts.
2. Remove the overhead console bezel by pulling down on its forward edge, disengaging two spring
clips. Disengage the two indexing tabs at the aft edge of the bezel, then remove the bezel.
3. Pull the right and left sides of the headliner inward, and the entire headliner forward and down to
separate the hook and loop fastening and gain enough room to access the back of the headset
hangers.
4. Disconnect the two headset hanger light connectors.
5. Remove the headliner.
VERIFICATION METHOD:
This procedure is complete when the headliner has been fully removed from the overhead console
bracket.
RELATED INFORMATION:
"Baggage Sidewall Panel Removal" on page 3-43
"Baggage Sidewall Panel Installation" on page 3-45
"Fine Fuel Filter" on page 10-30
"Rigging Roll Controls" on page 9-20
"Inspect Roll Cable Tension" on page 9-13
"Rigging Yaw Controls" on page 9-87
"Rigging Pitch Controls" on page 9-46
"Remove Roll Cables" on page 9-28
"Remove Fuel Tank (MY18+)" on page 10-15
"Remove Fuel Pressure Sensor" on page 6-67
"Remove Fine Fuel Filter" on page 10-30
3.6.2.2 Headliner Installation
Use this procedure to install the headliner.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
None
