FLIGHT CONTROLS / YAW CONTROLS 9-85
CHANGE C3 ICON A5 / MAINTENANCE MANUAL
RELATED INFORMATION:
"Re-Rigging Rudder Pedals" on page 9-103
9.10.3.3 Inspect Yaw Rigging
The following section contains the information required to perform the A5 maintenance inspection on
the rudder.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
ICA013055—Rudder Deflection Template
Parts Required
None
Aircraft System and Number
06—Flight Controls
Consumables
None
1. Position the rudder rigging template (ICA013055) or a protractor as shown in Figure 9-53, Center
the 0° indication of the rigging template or protractor with respect to the center of the tail section
under the rudder.
2. Swing the rudder surface back and forth by hand and verify it returns to a repeatable neutral
position. Record neutral deflection. The neutral position of the rudder should be 1°+/-1° trailing
edge right.
