6-48 ELECTRICAL SYSTEM / BILGE PUMP
ICON A5 / MAINTENANCE MANUAL CHANGE C2
CHAPTER 6
No
Special Tools Required
None
Parts Required
None
Aircraft System and Number
03—Electrical System
Consumables
None
TASK INSTRUCTIONS:
1. Remove the fuel tank if unable to perform the below steps with tank installed. (See “Remove Fuel
Tank (MY18+)” on page 10-15.)
2. Reaching down behind the fuel tank, disconnect the bilge pump hose from the pump by loosening
the hose clamp and pulling the hose off the pump’s barb.
3. Detach the pump body from the bottom strainer by depressing the lock bottom and turning
counter clockwise.
4. Remove the pump body, leaving the bottom strainer bonded to the bottom of the hull.
VERIFICATION METHOD:
The procedure is complete when the bilge pump has been removed.
6.6.3.5 Bilge Pump Installation (MY18+)
Use the following procedure to install the bilge pump (MY18+).
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
None
Parts Required
PUMP, BILGE, 12VDC 1.8A, 550GPH
