ELECTRICAL SYSTEM / BILGE PUMP 6-49
CHANGE C2 ICON A5 / MAINTENANCE MANUAL
TY24MX CABLE-TIE, NYLON 6-6, 30LBS, 5.50, TY-RAP
16-120-0340W HOSE, SHIELDS BILGEFLEX, .75, WHITE
3806 CLAMP, WORM DRIVE, MINI, .312X0.781
Aircraft System and Number
03—Electrical System
Consumables
3M FIRE BARRIER SILICONE SEALANT 2000+B
SILICONE ELASTOMER, ONE-COMPONENT
1. Clean the bilge area of any sand, stones, or other debris.
2. Remove the lower screen from the bilge pump and set it aside.
NOTE: It will not be used unless the strainer in the aircraft is damaged. To
bond in a new lower screen of the bilge pump, use 3M fire barrier
(201). Wipe excess sealant extruded from pin holes flush with top
side surface of bonding flange. Allow fire barrier to cure for 90
minutes before reinstalling the bilge pump.
