EQUIPMENT AND FURNISHINGS / EQUIPMENT AND FURNISHINGS GENERAL MAINTENANCE 8-15
CHANGE C1 ICON A5 / MAINTENANCE MANUAL
3. Install the standoff by inserting it into the throttle lever. See step 2. See Figure 8-8.
4. Insert left and right throttle handles. Install 2X Screws which secure throttle handles. Apply
LOCTITE
®
243™ and torque to 7-9 in-lbs. See Figure 8-7.
VERIFICATION METHOD:
Procedure is complete when the throttle handle and bezel is installed.
RELATED INFORMATION:
"Rigging Yaw Controls" on page 9-87
"Rigging Pitch Controls" on page 9-46
"GPS Mount and Radio Stack Bezel Installation" on page 8-16
8.2.6 GPS Mount and Radio Stack Bezel Removal
Use the following procedure to remove the GPS mount and Radio stack bezel.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
None
Parts Required
None
Aircraft System and Number
05—Equipment and Furnishings
Consumables
None
1. Remove the Garmin Aera 796 GPS
®
if installed.
2. Unfasten the Garmin GPS mounting module using a T15 Torx driver to remove the two 8-32
screws. Remove the GPS mount.
3. If the center console bucket and throttle bezel are still in place. (See “Center Console Bucket
Removal” on page 8-5.) (See “Throttle Handle and Bezel Removal” on page 8-10.)
