ICON A5 - Cockpit Floor Board Installation

INSPECTIONS / GENERAL INSPECTION TASKS 3-47
CHANGE C2 ICON A5 / MAINTENANCE MANUAL
CHAPTER 3
TASK INSTRUCTIONS:
1. Lift up on the aft edge of each aft floor board, separating the ball and socket fasteners, then lift
up on the forward edge in a similar way. Remove the aft floor board using care so as not to
scratch anything.
2. Remove each forward floor board by positioning the rudder pedals at mid-travel, then sliding the
forward floor board aft and out.
VERIFICATION METHOD:
The task is complete when the cockpit floor board has been removed.
RELATED INFORMATION:
"Seat Pan Removal" on page 3-52
"Rigging Roll Controls" on page 9-20
"Inspect Roll Cable Tension" on page 9-13
"Rigging Yaw Controls" on page 9-87
"Rigging Pitch Controls" on page 9-46
"Empty Weight and CG Measurement While on Gear" on page 3-30
"Empty Weight and CG Measurement While on Jackpoint Scales" on page 3-32
"Remove Roll Cables" on page 9-28
3.6.2.10 Cockpit Floor Board Installation
Use the following procedure to install the cockpit floor board.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
None
Parts Required
None
Aircraft System and Number
NA
Consumables
None
