3-52 INSPECTIONS / GENERAL INSPECTION TASKS
ICON A5 / MAINTENANCE MANUAL CHANGE C2
Consumables
None
1. Place seat back into position.
2. Place seat belt into channel.
3. Install the five seat back mounting bolts finger tight, then torque all to 26 in-lbs with a 3/8 wrench.
4. Use a T20 Torx driver and 3/8 wrench to install the seat back closeout.
5. Install the baggage floors. (See “Baggage Floor Installation” on page 3-42.)
6. Install the cockpit sidewall panels. (See “Cockpit Sidewall Panel Installation” on page 3-49.)
VERIFICATION METHOD:
The task was completed when the seat back is installed.
RELATED INFORMATION:
"Fuel Level Sensor Replacement" on page 6-72
"Baggage Floor Installation" on page 3-42
"Cockpit Sidewall Panel Installation" on page 3-49
"Install Fuel Bladder (MY17 Only)" on page 10-12
"Main Landing Gear (MLG) Removal" on page 14-37
"Main Landing Gear (MLG) Installation" on page 14-38
"Rigging Roll Controls" on page 9-20
"Inspect Roll Cable Tension" on page 9-13
"Rigging Yaw Controls" on page 9-87
"Rigging Pitch Controls" on page 9-46
"Seat Belt Replacement" on page 8-3
"Install Fuel Tank (MY18+)" on page 10-19
3.6.2.15 Seat Pan Removal
The following procedure is used to remove the seat pan.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
