ELECTRICAL SYSTEM / DOME LIGHT SWITCH 6-65
CHANGE C2 ICON A5 / MAINTENANCE MANUAL
RELATED INFORMATION:
"Overhead Console Component Replacement" on page 13-15
6.9.3.2 Install Dome Light Switch
Use the following task to install the dome light switch.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
A&P
Task Specific Training Required
No
Special Tools Required
None
Parts Required
R13-133A-01 (SWITCH, SPST, 30A)
Aircraft System and Number
03—Electrical System
Consumables
None
1. Install the new SWITCH, SPST, 30A into the overhead console frame and tighten with retaining
nut. Torque to finger tight.
2. Connect wire labeled T9924 to the short post of the switch and T9926 to the tall post of the
switch as shown in Figure 6-18.
