ICON A5 - Seat Pan Installation

INSPECTIONS / GENERAL INSPECTION TASKS 3-53
CHANGE C2 ICON A5 / MAINTENANCE MANUAL
CHAPTER 3
None
Parts Required
None
Aircraft System and Number
NA
Consumables
None
TASK INSTRUCTIONS:
1. Remove seat back. (See “Seat Back Removal” on page 3-50.)
2. Cut the cable tie at the top of the control stick boot, then unzip boot’s zipper.
3. Remove the aft cockpit floor board on the appropriate side. (See “Cockpit Floor Board Removal”
on page 3-46.)
4. Reaching underneath the seat pan, use a 1/2 wrench to remove the four attachment bolts and
washers. The forward two bolts are AN5C5A and the aft two bolts are AN5C6A.
5. Turn the seat pan over and remove the rudder pedal release cable by loosening the jam nut
nearest the cable end and running it off the threaded end of the housing. The cable can then be
freed from the seat pan by passing the cable through the slot in the cable clip, then disengaging
the cable’s free end from the release handle.
6. Remove the seat pan from the aircraft.
VERIFICATION METHOD:
The task is complete when the seat pan has been removed.
RELATED INFORMATION:
"Seat Back Removal" on page 3-50
"Cockpit Floor Board Removal" on page 3-46
"Rigging Roll Controls" on page 9-20
"Inspect Roll Cable Tension" on page 9-13
"Rigging Yaw Controls" on page 9-87
"Rigging Pitch Controls" on page 9-46
"Seat Belt Replacement" on page 8-3
"Remove Roll Cables" on page 9-28
3.6.2.16 Seat Pan Installation
Use the following task to install the seat pan.
TASK INFORMATION:
Type of Maintenance
