FLIGHT CONTROLS / ROLL CONTROLS 9-11
CHANGE C3 ICON A5 / MAINTENANCE MANUAL
CHAPTER 9
9.4 Roll Controls
9.4.1 Roll Controls Description
The ailerons control the roll of the aircraft by converting the left-right user input at the control stick and
changing the pitch of the ailerons. A series of cables and pulleys are used to make this possible. Proper
tensions and control cable health is required to achieve a predictable motion of the aircraft.
9.4.2 Roll Controls Diagram/Schematic
FIGURE 9-6
FUSELAGE ROLL SYSTEM
