ICON A5 - General Inspection Tasks; Removal and Installation of Inspection Panels and Fairings

3-34 INSPECTIONS / GENERAL INSPECTION TASKS
ICON A5 / MAINTENANCE MANUAL CHANGE C2
CHAPTER 3
3.6 General Inspection Tasks
3.6.1 Removal and Installation of Inspection Panels and Fairings
Removing and installing the aircraft inspection panels.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
Owner/Pilot
Task Specific Training Required
No
Special Tools Required
None
Parts Required
None
Aircraft System and Number
NA
Consumables
None
The A5 has the following access panels:
• Aft Bulkhead Baggage Panel in the baggage compartment.
• Water Rudder Access Panel on the empennage.
• Air Rudder Access Panel at the back of the empennage.
• 2X Horizontal Tail Tip Access Panel. There is one on each side, which is only visible with the tip
removed.
• 2X Wing Fold Access Panel located on the underside of each wing near the wing fold mecha-
nism.
• 2X Aileron Access Panel located on the underside of each wing near the aileron bellcrank
mechanism.
