6-38 ELECTRICAL SYSTEM / BATTERY
ICON A5 / MAINTENANCE MANUAL CHANGE C2
CHAPTER 6
9. Reconnect the battery terminals in the following order:
a. Positive Terminal Connectors T9181, T9054.
b. Negative Terminals Connectors T9069, T9074, T9076, T9182.
10. Install the Right Top Instrument Panel Cover. (See “Right Instrument Panel Top Panel Installation”
on page 8-18.)
VERIFICATION METHOD:
Turn the master switch on a verify that all electrical and avionics systems power up and function
correctly.
RELATED INFORMATION:
"Right Instrument Panel Top Panel Removal" on page 8-17
"Right Instrument Panel Top Panel Installation" on page 8-18
"Nose Landing Gear (NLG) Leg Assembly Removal" on page 14-60
"Nose Landing Gear (NLG) Leg Assembly Installation" on page 14-62
6.5.3.2 Charge Battery
Use this procedure to boost-charge the aircraft battery.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
Owner/Pilot
Task Specific Training Required
No
Special Tools Required
A 14.125±.125 VDC charge with current capability of at least 4.8 amperes for AGM batteries.
Parts Required
None
Aircraft System
03—Electrical System
Consumables
None
