14-60 LANDING GEAR / NOSE LANDING GEAR
ICON A5 / MAINTENANCE MANUAL CHANGE C2
CHAPTER 14
None
Aircraft System and Number
11—Landing Gear
Consumables
LOCTITE
®
243™
Start this procedure with a complete Beringer nose wheel and tire assembly (see Beringer Wheel and
Brake Maintenance Manual).
TASK INSTRUCTIONS:
1. Slide the AV-ICON-002 axle into the wheel assembly.
2. Slide the ICA011894 spacer onto the end of the axle.
3. Position the wheel assembly into the NLG fork.
4. Apply LOCTITE
®
243™ to the threads of the two AN4C11A bolts and install them through each
leg of the NLG fork and into the axle. Torque each to 44 in-lb
f
.
VERIFICATION METHOD:
Check that the wheel spins freely and that tire pressure is correct (45 psi).
RELATED INFORMATION:
"Nose Wheel Tire Leak" on page 14-80
14.7.2.3 Nose Landing Gear (NLG) Leg Assembly Removal
The following task should be used to remove the nose landing gear (NLG) leg assembly.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
None
Parts Required
None
Aircraft System and Number
