LANDING GEAR / NOSE LANDING GEAR 14-59
CHANGE C2 ICON A5 / MAINTENANCE MANUAL
CHAPTER 14
None
Aircraft System and Number
11—Landing Gear
Consumables
None
TASK INSTRUCTIONS:
1. Jack the aircraft up or weight the tail so that the nose gear is clear of the ground.
CAUTION: Use a safety block under the forward hull if weighting tail.
2. Use a 7/16 wrench to remove the two AN4C11A bolts on either side of the NLG fork.
3. Slide the wheel assembly out of the fork.
4. Remove the ICA011894 spacer and AV-ICON-002 axle.
5. Proceed to section “Nose Wheel Tire Leak” to add sealant to the Nose Wheel.
6. Proceed to the Beringer Wheel and Brake Maintenance Manual if doing further work on the
wheel.
VERIFICATION METHOD:
The procedure is complete when the nose landing gear wheel has been removed.
RELATED INFORMATION:
"Nose Wheel Tire Leak" on page 14-80
14.7.2.2 Nose Landing Gear (NLG) Wheel Installation
Use the following procedure to install the nose landing gear (NLG) wheel.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
None
Parts Required
