ICON A5 - Re-Rigging Rudder Pedals

FLIGHT CONTROLS / YAW CONTROLS 9-103
CHANGE C3 ICON A5 / MAINTENANCE MANUAL
CHAPTER 9
RELATED INFORMATION:
"Inspect Rudder Pedal Adjustment Mechanism" on page 9-5
"Adjust Rudder Pedal Rigging" on page 9-101
"Re-Rigging Rudder Pedals" on page 9-103
"Removal and Installation of Inspection Panels and Fairings" on page 3-34
9.10.4.4 Re-Rigging Rudder Pedals
Use this task to re-rig the rudder pedal rigging.
TASK INFORMATION:
Type of Maintenance
Heavy
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
Protractor or inclinometer
Parts Required
ICA009509 Control Cable
ICA009510 Control Cable
MS51844-23 Sleeves
AN100C-4 Thimbles
MS24665-151 Cotter Pins
Aircraft System and Number
06—Flight Controls
Consumables
None
TASK INSTRUCTIONS:
1. Remove existing rudder pedal cables. Cut cable just after the MS51844-23 swage sleeve and
remove.
