EQUIPMENT AND FURNISHINGS / EQUIPMENT AND FURNISHINGS GENERAL MAINTENANCE 8-13
CHANGE C1 ICON A5 / MAINTENANCE MANUAL
FIGURE 8-9
THROTTLE BEZEL REMOVAL
VERIFICATION METHOD:
Procedure is complete when the throttle handle and bezel is removed from the aircraft.
RELATED INFORMATION:
"Rigging Yaw Controls" on page 9-87
"Rigging Pitch Controls" on page 9-46
"GPS Mount and Radio Stack Bezel Removal" on page 8-15
8.2.5 Throttle Handle and Bezel Installation
Use the following procedure to remove the throttle handle and bezel.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
