ICON A5 - Throttle Handle and Bezel Removal

8-10 EQUIPMENT AND FURNISHINGS / EQUIPMENT AND FURNISHINGS GENERAL MAINTENANCE
ICON A5 / MAINTENANCE MANUAL CHANGE C1
CHAPTER 8
3. Install 2x screws which secure the center armrest. Apply ICA012078 lubricant and torque to 12
inlbs. See Figure 8-4.
4. Install 2x screws which secure the FWD edge of the center console bucket. Apply ICA012078
lubricant and torque to 12 inlbs. See Figure 8-3.
VERIFICATION METHOD:
Procedure is complete when the center console is installed in the aircraft.
RELATED INFORMATION:
"Inspect Yaw Cable Tension" on page 9-80
"Rigging Yaw Controls" on page 9-87
"Rigging Pitch Controls" on page 9-46
"GPS Mount and Radio Stack Bezel Installation" on page 8-16
8.2.4 Throttle Handle and Bezel Removal
Use the following procedure to remove the throttle handle and bezel.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools
No
Parts Required
None
Aircraft System and Number
05—Equipment and Furnishing
Consumables
LOCTITE
®
243™
TASK INSTRUCTIONS:
1. Remove center console bucket. (See “Center Console Bucket Removal” on page 8-5.)
