8-16 EQUIPMENT AND FURNISHINGS / EQUIPMENT AND FURNISHINGS GENERAL MAINTENANCE
ICON A5 / MAINTENANCE MANUAL CHANGE C1
CHAPTER 8
4. Use a T15 Torx driver to remove the four 8-32 screws that attach the radio stack bezel.
5. Lift up on the bottom edge of the radio stack bezel, pulling it away from the center console and
pivoting it about its upper edge. The tabs on the upper edge of the bezel of the GPS mount to
rotate outward in a similar fashion, releasing the tabs at its top edge.
6. Remove the radio stack bezel and disconnect the electrical harness D9011J from the instrument
panel cross beam. Disconnect transponder harness (D9068P) and the Radio harness (D9063P).
Disconnect the static line to the transponder control head to completely release radio stack
bezel.
VERIFICATION METHOD:
The procedure is complete when the GPS mount and radio stack bezel has been removed.
RELATED INFORMATION:
"Center Console Bucket Removal" on page 8-5
"Throttle Handle and Bezel Removal" on page 8-10
"GPS Mount and Radio Stack Bezel Installation" on page 8-16
8.2.7 GPS Mount and Radio Stack Bezel Installation
Use the following procedure to install the GPS mount and Radio stack bezel.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
None
Parts Required
None
Aircraft System and Number
05—Equipment and Furnishings
Consumables
None
