6-60 ELECTRICAL SYSTEM / LANDING AND TAXI LIGHTS
ICON A5 / MAINTENANCE MANUAL CHANGE C2
CHAPTER 6
RELATED INFORMATION:
"Right Instrument Panel Top Panel Removal" on page 8-17
"Left Instrument Panel Top Panel Removal" on page 8-19
"Install Landing and Taxi Lights" on page 6-60
6.8.3.2 Install Landing and Taxi Lights
Use the following instructions to install the landing and taxi lights.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
13 INCH POUND TORQUE WRENCH
Parts Required
LIGHT, TAXI AND LANDING, RH
LIGHT, TAXI AND LANDING, LH
NUT, SLFLKG, RDC HEX, CRES, 8-32
WASHER, FLAT, CRES, #8, .032 THK, PSVT FNSH
Aircraft System and Number
03—Electrical System
Consumables
None
TASK INSTRUCTIONS:
1. Install LH and RH light assembly onto existing studs as shown using retained washers and nuts.
See Figure 6-16.
2. Torque nuts to 13 in-lbs. Check that hardware is secure.
3. Plug D9033P connector on main wire harness into receptacle on LH light.
