ELECTRICAL SYSTEM / LANDING AND TAXI LIGHTS 6-61
CHANGE C2 ICON A5 / MAINTENANCE MANUAL
CHAPTER 6
4. Plug D9034P connector on main wire harness into receptacle on RH light.
5. Turn on the landing and taxi lights switch in the radio bezel to verify lights are working correctly.
VERIFICATION METHOD:
This task is done when the landing and taxi lights are installed and working.
RELATED INFORMATION:
"Right Instrument Panel Top Panel Installation" on page 8-18
"Left Instrument Panel Top Panel Installation" on page 8-21
"Remove Landing and Taxi Lights" on page 6-58
